Silver Cadmium Oxide Composite Rivet Contact Material
Inquiry
Product introduction
According to different working conditions and application scenarios, different design structures and solutions are adopted, combined with different contact materials and composite forms, and various types such as integral type, two-composite type, and three-composite type can be prepared. The products can realize deep processing such as riveting or welding. , not only simplifies the manufacturing process of contact parts, improves production efficiency, and reduces costs, but also improves the assembly accuracy and reliability of components. Mainly used in automotive appliances, household appliances, relays, contactors, thermostats, timers, and electronic appliances.
Physical Properties
| Makings | Density g/cm³ | Resistivity μΩ.cm | Soft state hardness HB | Conductivity MS/m | Conductivity %IACS |
| AgCdO(8) | ≥9.90 | ≤2.10 | ≥65 | ≥48 | ≥82 |
| AgCdO(10) | ≥9.80 | ≤2.40 | ≥66 | ≥42 | ≥72 |
| AgCdO(12) | ≥9.70 | ≤2.60 | ≥68 | ≥38 | ≥66 |
| AgCdO(15) | ≥9.60 | ≤2.80 | ≥71 | ≥36 | ≥62 |
Ingredient Content
| Makings | Composition wt% | ||
| Ag | CdO | Total impurities | |
| AgCdO(8) | Tolerance | 8±1.0 | ≤0.3 |
| AgCdO(10) | Tolerance | 10±1.0 | |
| AgCdO(12) | Tolerance | 12±1.0 | |
| AgCdO(13) | Tolerance | 13±1.0 | |
| AgCdO(15) | Tolerance | 15±1.0 | |
Product parameters
Centred Services
Wenzhou Hongfeng Electrical Alloy Co., Ltd. (hereinafter referred to as “Wenzhou Hongfeng”), founded in September 1997. The main products include electrical contact materials, metal-matrix engineered composite materials, cemented carbide materials, high-performance extremely thin lithium copper foil, and intelligent equipment, providing customers with integrated functional solutions from material research and development to component manufacturing, and then intelligent manufacturing. As Silver Cadmium Oxide Composite Rivet Contact Material company in China, the products are widely applied in industrial manufacturing, intelligent transportation systems, smart homes, communication information, aerospace, mining, machinery manufacturing, medical, and other fields.From quotation to delivery, we provide one-stop customer service, respond quickly to customer needs, solve problems efficiently, and complete delivery; in addition, we can also provide professional material design, process optimization, sample preparation testing, mass production supply, and technical support through services such as professional material design, process optimization, and technical support. Meet customer needs for high-performance alloy materials.
-
Materials Design
And DevelopmentDesign and development of new alloy functional composite materials can be carried out according to customer needs and application requirements.
-
Manufacturing Process
OptimizationThe manufacturing process of new alloy functional composite materials can be optimized for customers.
-
Sample Preparation
And TestingWe can provide customers with sample preparation and testing services for new alloy functional composite materials.
-
Mass Production
And SupplyOnce the new alloy functional composite materials are mass-produced and provide stable and reliable supply.
-
Technical Support
And ConsultingHongfeng can also provide relevant technical support and consulting services to customers. Silver Cadmium Oxide Composite Rivet Contact Material Suppliers.
